Slider

Name: Potato
Author: Potato

Configure a continuous numeric slider in Potato with custom min, max, step size, default value, and optional label display for granular rating and scoring tasks.

The slider type provides a draggable slider for selecting numeric values within a range. Ideal for confidence ratings, intensity scores, or any continuous numerical input.

Slider annotation interface Draggable slider for continuous numeric annotation in Potato

Basic Configuration

yaml

annotation_schemes:
  - name: "confidence"

Configuration Options

Field	Type	Required	Description
`name`	string	Yes	Unique identifier for the annotation
`description`	string	Yes	Instructions shown to annotators
`annotation_type`	string	Yes	Must be `"slider"`
`min`	number	Yes	Minimum slider value
`max`	number	Yes	Maximum slider value
`step`	number	No	Increment value (default: 1)
`default`	number	No	Initial slider position
`min_label`	string	No	Label for minimum end
`max_label`	string	No	Label for maximum end
`show_value`	boolean	No	Display current value (default: true)

Examples

Confidence Rating

yaml

- name: "confidence"

Intensity Scale

yaml

- name: "intensity"

Percentage Input

yaml

- name: "agreement"

Output Format

The slider annotation outputs a single numeric value:

json

{
  "id": "item_1",
  "annotations": {
    "confidence": 75
  }
}

When to Use Slider vs Number Input

Use Slider when you want annotators to make quick, intuitive selections on a continuous scale
Use Number Input when you need precise values or when the range is very large

Best Practices

Set sensible defaults - Place the default at a meaningful position (often the midpoint)
Use endpoint labels - Help annotators understand what the scale represents
Choose appropriate step sizes - Smaller steps for fine-grained distinctions, larger for coarse ratings
Keep ranges intuitive - 0-100 or 1-10 are familiar to most annotators
