Speaker Diarization
Segment and label speakers in multi-party conversations following AMI Meeting Corpus guidelines.
audio annotation
Configuration Fileconfig.yaml
task_name: "Speaker Diarization"
# Server configuration
server:
port: 8000
# Audio settings
audio:
enabled: true
display: waveform
waveform_color: "#8B5CF6"
progress_color: "#A78BFA"
speed_control: true
speed_options: [0.5, 0.75, 1.0, 1.5]
keyboard_controls:
play_pause: "space"
rewind_5s: "left"
forward_5s: "right"
# Data configuration
data_files:
- path: data/meeting_segments.json
audio_field: audio_file
# Annotation schemes
annotation_schemes:
# Number of speakers
- annotation_type: radio
name: num_speakers
description: "How many distinct speakers are in this segment?"
labels:
- "1 speaker"
- "2 speakers"
- "3 speakers"
- "4 speakers"
- "5+ speakers"
# Speaker turns (span annotation would be ideal here)
# For now using structured fields
- annotation_type: text
name: speaker_turns
description: "List speaker turns with timestamps (e.g., '0:00-0:15 Speaker A, 0:15-0:30 Speaker B')"
textarea: true
placeholder: "0:00-0:15 Speaker A\n0:15-0:30 Speaker B\n..."
# Overlapping speech
- annotation_type: radio
name: overlap_present
description: "Is there overlapping speech (multiple speakers at once)?"
labels:
- No overlap
- Minor overlap (brief interruptions)
- Moderate overlap
- Significant overlap (hard to distinguish)
# Speaker characteristics
- annotation_type: multiselect
name: speaker_types
description: "What types of speakers are present? (Select all)"
labels:
- Male adult
- Female adult
- Child
- Elderly
- Non-native speaker
- Cannot determine
# Audio events
- annotation_type: multiselect
name: audio_events
description: "Non-speech events present (select all)"
labels:
- Laughter
- Coughing
- Throat clearing
- Paper rustling
- Typing
- Door sounds
- Phone ringing
- Background music
- Extended silence
- None
# Recording quality
- annotation_type: likert
name: recording_quality
description: "How clear is the recording for speaker identification?"
size: 5
min_label: "Very poor"
max_label: "Excellent"
# Difficulty
- annotation_type: likert
name: difficulty
description: "How difficult was it to identify speaker turns?"
size: 5
min_label: "Very easy"
max_label: "Very difficult"
# User settings
allow_all_users: true
instances_per_annotator: 50
# Output
output:
path: annotations/
format: json
Get This Design
This design is available in our showcase. Copy the configuration below to get started.
Quick start:
# Create your project folder mkdir speaker-diarization cd speaker-diarization # Copy config.yaml from above potato start config.yaml
